Mullite Bricks
Mullite brick is a high-performance high-alumina refractory brick with mullite (3Al₂O₃·2SiO₂) as the main crystal phase, the only stable high-temperature crystal phase material in the Al₂O₃-SiO₂ system. It features extremely strong high-temperature rigidity (no deformation above 1600℃ for long-term use, ultra-low creep), excellent thermal shock performance (low thermal expansion, anti-cracking/peeling), outstanding corrosion resistance (resistant to acidic/neutral slag scouring and melt corrosion, little pollution), high room-temperature compressive strength and moderate apparent porosity, with complete specifications and flexible customization, widely applicable to various high-temperature industries, making it the preferred refractory material for the core lining of various high-temperature kilns.
Product Classification:
1. Sintered Mullite Brick: Made from bauxite and silica (1600-1700℃ sintering), Al₂O₃ 65%-72%. Cost-effective, mature, suitable for medium-high temperature conventional conditions; available in standard/special-shaped bricks, widely used in building materials and metallurgy kilns.
2. Fused Mullite Brick: Electric-fused (above 1900℃), coarser crystal, denser structure. Al₂O₃ 70%-75%, superior thermal shock/corrosion resistance, ultra-low creep. Suitable for core high-temperature (above 1650℃) strong-scouring conditions (glass melting furnaces, high-end metallurgy).
3. Zircon Mullite Brick: Mullite + zircon (ZrSiO₄) additive (1650-1720℃ sintering). Al₂O₃ 68%-75%, ZrO₂ 8%-15%, stronger erosion resistance. Used in key glass melting furnace parts and high-erosion non-ferrous smelting furnaces.
4. High-Purity Mullite Brick: High-purity alumina/silica, Fe₂O₃≤0.2%, Al₂O₃ 72%-78%, refractoriness above 1850℃. Pollution-free, excellent high-temperature stability, for high-purity scenarios (precision metallurgy, electronic ceramic kilns).
5. Mullite Prefabricated Parts: Customized by kiln size/shape, no on-site cutting, high construction efficiency, good sealing. Suitable for irregular kiln sections (hot blast stoves, cracking furnaces), reducing brick falling risk.
|
Products
|
Three Low Mullite
|
Sintered Mullite
|
Sillimanite Mullite
|
Fused Mullite
|
||||
|
Index
|
RBTM-47
|
RBTM-65
|
RBTM-70
|
RBTM-75
|
RBTA-60
|
RBTA-65
|
RBTFM-75
|
|
|
Refractoriness(℃) ≥
|
1790
|
1790
|
1790
|
1790
|
1790
|
1790
|
1810
|
|
|
Bulk Density(g/cm3) ≥
|
2.42
|
2.45
|
2.50
|
2.60
|
2.48
|
2.5
|
2.70
|
|
|
Apparent Porosity(%) ≤
|
12
|
18
|
18
|
17
|
18
|
18
|
16
|
|
|
Cold Crushing Strength(MPa)
|
60
|
60
|
70
|
80
|
70
|
70
|
90
|
|
|
Permanent Linear Change(%)
|
1400°×2h
|
+0.1
-0.1
|
|
|
|
|
|
|
|
1500°×2h
|
|
+0.1
-0.4
|
+0.1
-0.4
|
+0.1
-0.4
|
+1
-0.2
|
±0.2
|
±0.1
|
|
|
Refractoriness Under Load@0.2MPa(℃) ≥
|
1520
|
1580
|
1600
|
1600
|
1600
|
1620
|
1700
|
|
|
Creep Rate@0.2MPa
1200°×2h(%) ≤
|
0.1
|
―
|
―
|
―
|
―
|
―
|
―
|
|
|
Al2O3(%) ≥
|
47
|
64
|
68
|
72
|
60
|
65
|
75
|
|
|
Fe2O3(%) ≤
|
1.2
|
0.8
|
0.8
|
0.7
|
1.0
|
0.8
|
0.5
|
|
1. Metallurgical Industry: Hot blast stove top, blast furnace shaft, ladle lining, non-ferrous metal smelting furnace;
2. Building Materials Industry: High-temperature zone of ceramic kiln, transition zone of cement rotary kiln, refractory tunnel kiln;
3. Glass Industry: Regenerator, channel, launder and working pool side wall of glass melting furnace;
4. Chemical Industry: Petrochemical cracking furnace, high-temperature calciner, catalyst roasting furnace;
5. High-End Field: Electronic ceramic kiln, precision metallurgical furnace (suitable for high-purity type).
